1535nm Diode Pumped Solid-state DPSS Laser - 200μJ

Name: 1535nm Diode Pumped Solid-state DPSS Laser - 200μJ
Brand: ERDI TECH LTD
SKU: ER200-03
Price: 140 USD
Availability: InStock

ER200-03

Selling point

The erbium laser is a solid-state laser that uses a semiconductor diode as the pump source（DPSS laser） and erbium-doped glass as the gain medium. It emits at 1535 nm and as an eye-safe laser. Developed by ERDI TECH LTD, this high peak power laser uses phosphate glass doped with Er³⁺and Yb³⁺, and operates at wavelengths that are safe for human eyes. It features high peak power, narrow pulse width, no need for temperature control during operation, compact size, light weight, and low power consumption.

MOQ

After-Sales Support

OEM/ODM Capabilities

Support Global Delivery

30-day TrialTake

3D Model Download

Information Download

DESCRIPTION

It's a low-pulse erbium laser developed by ERDI TECH LTD. It has an output wavelength of 1.54 μm and complies with the Class 1 eye safety standard. Featuring strong temperature adaptability, it can operate in environments ranging from -40°C to +65°C. The output energy is greater than or equal to 200 μJ, making it suitable for measuring distances from 3 to 8km. The laser measures 25 × 8 × 7 mm and weighs only 8 g, making it highly convenient for installation and integration into telescopes, drones, rifle scopes, and other instruments.

TECHNICAL SPECIFICATIONS

ER200
Optical
Wavelength	1535 nm
Laser Energy	200 μJ
Laser Pulse width(FWHM)	5 ns
Pulse Repetition Rate	10 Hz
Pulse Energy Stability	10%
Raw Beam Diameter	0.3 mm
Beam Divergence	8 mrad
Laser Modes	TEM00
Environmental
Operation Temperature	-40 ℃~+65 ℃
Storage Temperature	-55 ℃~+85 ℃
Shock	1500 G, 0 .5 ms
Vibration	20~2000 Hz/20 G
Lifetime	>1million shots
Mechanical
Laser Head Size	21×8×6.8mm3
Laser Head weight	7 g
Driver
Voltage	2 V
Current	10 A
Driver Pulse width	<2.4 ms
